Input voltage: 90 - 132 V AC/173 - 264 V AC
Input current: 2.3 A (115 V AC); 1.2 A (230 V AC)
Inrush current after 1 ms: max. 20 A
Primary fusing external: max. 20 A
Frequency: 50 - 60 Hz
Standards: EN 60950-1, EN 61204-3, EN 55022 B, EN 61000-3-2
Mounting method: DIN-rail mountable TH35 (EN 60715)
Efficiency: 84% (115 V AC); 86% (230 V AC)
Relative humidity: 20 - 90%, no condensation
Dimensions H x W x D: 125x50x125 mm
Temperature range: 0 - 40 degrees Celsius, - 50 degrees Celsius derating (storage temperature -20 - 85 degrees Celsius)
Output voltage: 24 V DC /-1%
Output current: 5 A ( 40 degrees Celsius); 4 A ( 55 degrees Celsius)
Mains failure bridging time: min. 40 ms (115 V AC); min. 40 ms (230 V AC)
Ripple: max. 20 mVrms
Unit protection: short-circuit and overload protected
Spikes: max. 60 mV p-p
LED display: LED (green) for output voltage
Parallel usage/serial usage: no/yes (max. 2 units)
