This product is a replacement for the following obsolete Leuze product:
HRTL 3B/66.C2, 200-S8 | 50114764

Series: 3C
Operating principle: Scanning principle with background suppression
Operating range, white 90%: 0.015 - 0.55 m
Operating range, gray 18%: 0.015 - 0.44 m
Operating range, black 6%: 0.015 - 0.25 m
Operating range limit: 0.015 m
Light source: Laser, Red
Laser class: 2, IEC/EN 60825-1:2007
Light spot size: 1 mm
Shift angle: Typ. /- 2 degrees
Switching frequency: 3000 Hz
Response time: 0.16 ms
Protective circuit: Overvoltage protection, Polarity reversal protection, Short circuit protected
Supply voltage: 10 - 30 V, DC
Number of digital switching outputs: 2
Output 1 switching element: Transistor, PNP
Output 1 switching principle: Light switching
Output 2 switching element: Transistor, PNP
Output 2 switching principle: Dark switching
Type of connection: Cable with connector
Cable length: 200mm
Thread size: M8
Design: Cubic
Type of fastening: Via optional mounting device, Through-hole mounting
Operational controls: Multiturn potentiometer
Degree of protection: IP 67, IP 69K
Certifications: c UL US

Diffuse sensor with powerful background suppression for reliable object detection on nearly any background with visible and infrared light. Laser version available for high-precision positioning applications.

Exact range adjustment through 8-turn potentiometer
Also available with infrared light
Especially designed for the detection of fast events and small parts
For applications with high demands on positioning and reproducibility
Extended detection range with very good b/w ratio as laser type

View the complete product specifications

Additional Info

Brand Leuze
Component Type Photoelectric Sensor Cubic
Connection Cable with M8 Plug
Housing Material Plastic
Leuze Product Series Leuze 3 Photoelectric Sensor Cubic
Operating Range 0.015-0.55 m
Sensing Method Diffuse with Background Suppression
