Compatible with the following transmitter:

MLC501T30-1650 | 68004316



In order to install this light curtain you will also need to purchase a safety relay, 2 connector cables, and two mounting bracket sets: safety relay, connection cables, and mounting brackets.



Application: Hand protection

Characteristic Parameter Type: 4,IEC/EN 61496

Resolution: 30 mm

Protective field height: 1650 mm

Response time:15 ms

Supply voltage: 24 V, DC, -20-20 %

Number of safety-related switching outputs (OSSDs): 2 Piece(s)

Safety-related switching output 1: Switching element Transistor, PNP

Safety-related switching output 2: Switching element Transistor, PNP

Type of connection: Connector

Thread size: M12

No. of pins: 5 -pin

Housing material: Metal, Aluminum

Lens cover material: Plastic (PMMA)

Degree of protection: IP 65

Function package: Basic

Functions: Automatic start/restart, Transmission channel changeover



The type 4 Basic model with AIDA-compliant pin assignment



The devices have a plug connection with AIDA-compliant M12 pin assignment (Automatisierungs-Initiative deutscher Automobilisten (AIDA) = Automation Initiative of German automobile manufacturers).



Advantages:

Automatic start/restart

Optimal handling

Range reduction on demand

Universal application due to standard functions

Short delivery times and global availability

QR code on the sensor for quick service information
