Series: 96
Operating principle: Diffuse reflection principle
Operating range, white 90%: 0.02 - 0.8 m
Operating range, gray 18%: 0.06 - 0.42 m
Operating range, black 6%: 0.08 - 0.29 m
Operating range limit, white 90%: 0.02 - 1.2 m
Operating range limit, gray 18%: 0.06 - 0.95 m
Operating range limit, black 6%: 0.08 - 0.57 m

Switching output 1: Transistor, PNP
Switching principle: Light switching
Switching output 2: Transistor, PNP
Switching Principle: Dark switching
Light source: LED, Infrared
Switching frequency: 1000 Hz
Response time: 0.5 ms
Readiness delay: 200 ms
Number of digital switching outputs: 2
Type of connection: Terminal
Number of pins: 5-pin
Degree of protection: IP 67
Certifications: c UL US

View the complete product specifications
