Input voltage: 230 V AC /-5%
Input current: 3.75 A (230 V AC)
Inrush current: 92.8 A (230 V AC)
Short-circuit current: 87.8 A (230 V AC)
Frequency: 50 - 60 Hz
Test isolation voltage: 4 kV (prim./sec.)
Standards: EN 61558-1, EN 61558-2-6, EN 62041 category 0
Mounting method: Key-hole mounting
Fixing centers a x b x c: 92x135x7 mm
Drill hole diameter: 7x11 mm
Dimensions H x W x D: 117x174x160 mm
Temperature range: -20 - 60 degrees Celsius (storage temperature -40 - 80 degrees Celsius)
Output voltage: 24 V AC (SELV)
Output rating: 800 VA

Different situations require different voltages. Transformers have to be just as flexible as the application. Murrelektronik's range provides you with the flexibility you need! No matter if it's an isolation transformer, control transformer, or safety transformer - Murr has the right solution for any application. Murrelektronik's transformers are reliable, safe and their approvals and voltage ranges make them ideal for worldwide use.

Murrelektronik Transformers Advantages:
Approvals for the global market
Flexible and versatile
Customized solutions

Additional Info

Brand Murrelektronik
Component Type Safety Transformer
Input Voltage 230V AC
Murr Product Series Murrelektronik MET
Output Voltage 24V AC
Power 800VA
