Input voltage: 230/400 V AC
Input current: 0.78 A (230 V AC); 0.45 A (400 V AC)
Inrush current: 6 A (230 V AC); 3.46 A (400 V AC)
Short-circuit current: 9.5 A (230 V AC); 5.5 A (400 V AC)
Frequency: 50 - 60 Hz
Test isolation voltage: 4 kV (prim./sec.)
Standards: EN 61558-1, EN 61558-2-4, EN 62041 category 0
Drill hole diameter: 4.8x8.4 mm
Mounting method: Long-hole mounting or DIN-rail mountable TH35 (EN 60715)
Fixing centers a x b x c: 86.5x84x4.8 mm
Dimensions H x W x D: 101x96x106 mm
Temperature range: -20 - 40 degrees Celsius (storage temperature -40 - 80 degrees Celsius)
Output voltage: 230 V AC
Output rating: 160 VA

Different situations require different voltages. Transformers have to be just as flexible as the application. Murrelektronik's range provides you with the flexibility you need! No matter if it's an isolation transformer, control transformer, or safety transformer - Murr has the right solution for any application. Murrelektronik's transformers are reliable, safe and their approvals and voltage ranges make them ideal for worldwide use.

Murrelektronik Transformers Advantages:
Approvals for the global market
Flexible and versatile
Customized solutions



Additional Info

Brand Murrelektronik
Component Type Control and Isolation Transformer
Input Voltage 230-400V AC
Murr Product Series Murrelektronik MST
Output Voltage 230V AC
Power 160VA
